Introducing, the Mars’s 450BPH 5 Gallon 19L 20L Bottled Water Filling Capping Machine – the ultimate solution for easily filling and capping large water bottles!
This high-quality machine is designed to efficiently fill and cap up to 450 bottles per hour, making it perfect for medium to large-scale water bottling operations. Whether you are a small business looking to expand your bottling capabilities or a large enterprise in need of a reliable production line, the Mars 450BPH Filling Capping Machine is a smart choice.
With its user-friendly design, this machine is easy to operate and maintain, saving you time and effort. The filling process is precise and consistent, ensuring that each bottle is filled to the correct capacity every time. The capping mechanism is robust and reliable, securely sealing each bottle to prevent leaks and contamination.
This machine is compatible with 5-gallon, 19L, and 20L water bottles, making it versatile and adaptable to your specific needs. Whether you are producing purified drinking water, mineral water, or distilled water, the Mars Filling Capping Machine can handle it all.
Constructed from durable materials, this machine is built to last and withstand the rigors of daily use. Its compact size allows it to fit comfortably in your production facility without taking up too much space. The Mars brand is known for its commitment to quality and innovation, ensuring that you are investing in a product that will deliver exceptional performance for years to come.
In addition to its efficiency and reliability, the Mars’s 450BPH 5 Gallon Bottled Water Filling Capping Machine is also highly cost-effective. By streamlining your bottling process and reducing manual labor, this machine can help you save money in the long run and increase your overall productivity.
Don't miss out on the opportunity to upgrade your bottling operation with the Mars’s 450BPH 5 Gallon 19L 20L Bottled Water Filling Capping Machine. Trust in the Mars brand and experience the difference that quality and precision can make in your business. Place your order today and start enjoying the benefits of this exceptional machine
450BPH 5 Gallon 19L 20L Bottled Water Filling Capping Machine
5 gallon jar filling machine Introduce
This mineral water machine specially produces gallons bottled drinking water, whose types (b/h) are: 100 type, 200 type, 300 type, 450 type, 600 type, 900 type, 1200 type and 2000 type
5 gallon jar filling machine Feature :
1. The 5 gallon jar filling machine integrates bottle washer, filler and sealer into unit, Multiple injections of washing and sterilizing and bleaching are used in bottle water filling machine
2. The sealer can seal bottle caps qutomatically
3. 5 gallon jar filling machine equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy
5 Gallon jar filling machine Main Technical parameters
| Main Technical parameters | |||||||
| Model | QGF-150 | QGF-300 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 | QGF-2000 |
| Filling heads | 1 | 2 | 3 | 4 | 8 | 12 | 16 |
| volume (L) | 18.9 | ||||||
| Barrel size - mm | - φ 270×490 | ||||||
| Capacity (b/h) | 100-150 | 240-300 | 400-450 | 600 | 900 | 1200 | 2000 |
|
Gas pressure (mpa) |
0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
|
Gas consumption (m3 /min) |
0.37 | 0.6 | 0.6 | 1.2 | 2.2 | 3 | 4.5 |
|
Motor power (kw) |
1.75 | 3.22 | 4.8 | 8.5 | 8.5 | 8.5 | 8.5 |
|
Rated voltage (V) |
220/380V, 50/60Hz | ||||||
Outline dimension (mm) |
3790×650×1550 | 3550×800×1800 | 3550×1200×1800 |
3650×1500×1800 |
2200×1860×2700 |
2560×2350×2750 |
3100×2800×2750 |
| Weight (kg) | 800 | 1100 | 1400 | 1700 | 2000 | 2300 |
2800 |
5 Gallon Jar Filling Capping Machine
|
Q1 What is the difference between your 3-in-1 monoblock water filling machine and a standalone filler — which is better for a small factory? |
For a small factory, a 3-in-1 monoblock (rinsing, filling, capping) is better because it saves space, reduces manual handling, lowers contamination risk, and is more cost-efficient for production speeds up to 12,000 BPH.
A standalone filler costs less upfront but requires more floor space, extra conveyors, and more labor, making it less efficient for small-scale automated lines.
Verdict:3-in-1 monoblock is the smarter choice for most small factories. |
|
Q2 Can this machine fill both small PET bottles (250ml-1.5L) and large 5-gallon barrels on the same unit? |
250ml to 1.5L botle filling machine are different with 5 gallon barrels, it means it need separate machine to fill them. |
|
Q3 What is the filling speed (BPH) for a 500ml bottle on your most popular water filling machine model? |
The most popular high-speed rotary model typically fills 500ml water bottles at 6000-12,000 BPH, while advanced industrial configurations reach 36,000 BPH |
|
Q4 What type of filling valves do you use — gravity or pressure — and how many filling heads are standard? |
Water filling machine normally use gravity filling valve, while vacuum pressure valve also can be used which can fill juice in same machine. With more filling level accuracy. |
|
Q5 How long does changeover take when switching between different bottle sizes? |
Changeover time typically ranges from 30 minutes to 1 hours for PET bottle water filling machine. |
|
Q6 What material is the filling machine body and all product-contact parts made of? |
The filling machine body is typically made of carton steel with SS304 cover, and product-contact parts are made of SS304 or SS316L stainless steel. |
|
Q7 Can the machine run 24 hours continuously, and what is the recommended maintenance interval? |
Yes, the machine is designed for 24/7 continuous operation. Recommended maintenance interval: every 500–1,000 operating hours or as specified in the manual. |
|
Q8 What is the minimum order — can I buy just one filling machine without a complete line? |
Yes, single filling machines are available with no minimum for a full line. Minimum order quantity (MOQ) is typically 1 unit. |
|
Q9 What is the power consumption of a standard 18-head water filling machine? |
The power consumption of a standard 18-head water filling machine is typically between 4-5Kw |
|
Q10 If a filling valve is damaged, how do I get a replacement part and how long does it take to ship? |
Mars packing machinery is professional filling machine factory,located in Zhangjiagang city,China. We can provide both machine and spare parts service. If a filling valve damaged, we can ship out within 1 week by express courier. |
